Automatic Metal Steel Coil Trimming Line

Leveling and traverse cutting link

Author:admin Time:2018-03-28

Leveling and traverse cutting link

detailsProblems(8)Online order


Steel plate leveling cutting unit has high high-efficient constant shearing plate, bending material uncoiling, leveling and shearing of different specifications of the plate, sheet metal processing industry is essential for efficient processing lines.

The sheet behind the set can increase the finished cutting board sizing cutting system will collect the chop. Applicable to the container, machinery manufacturing, home appliances, automotive, stainless steel products, light industry and other industries.

Two, structural description

Composition: it is composed of feeding car, uncoiler, demolition of the entrainment feeding machine, leveling machine, looper, sizing device, shearing machine, conveyor, chopping board system;

High performance PLC programmable control system control;

Structural design of reliable hydraulic pneumatic system, high strength and high rigidity;

Three, technical parameters

No. Com
modity
Raw
mate
rial
   THK
(mm)
  Width
(mm)
      ID
(mm)
    OD
(mm)
weight
(T)
Length
arrarge
(mm)
Slits
(mm)
Slit
tole
rance
(mm)
Smoo
thness
(mm
/m2)
Speed
(m/
min)
Capa
city
(KW)
Flood space
(m)
1 6.0*1600 stain
less
steel
、Cold-Rollrd
、Galv
nized
coil
Q235、   Q345、
 B510
1.0-6.0 600-  1600 Φ508/Φ610 ≤Φ2000 ≤35 1000-12000 ≤±0.5 ≤±1.5 ≤1.5 ≤30 ~155 35*8
2 8.0*1600 2.0-8.0 600-  1600 Φ508/Φ610 ≤Φ2000 ≤35 1000-12000 ≤±0.5 ≤±1.5 ≤1.5 ≤30 ~180 35*8
3 9.0*1600 2.0-9.0 600-  1600 Φ508/Φ610 ≤Φ2000 ≤35 1000-12000 ≤±0.5 ≤±1.5 ≤2.0 ≤20 ~195 35*8.5
4 10*1600 2.0-10 800-1600 Φ508-Φ760 ≤Φ2000 ≤35 1000-12000 ≤±0.5 ≤±1.5 ≤2.0 ≤20 ~240 42*8
5 12*2000 3.0-12 1000-2000 Φ508-Φ760 ≤Φ2000 ≤35 1000-12000 ≤±0.5 ≤±1.5 ≤2.0 ≤16 ~255 50*10
6 12*1800 3.0-12 800-1800 Φ508-Φ760 ≤Φ2200 ≤35 1000-12000 ≤±0.5 ≤±1.5 ≤2.0 ≤16 ~255 50*10
7 16*2000 4.0-16 1000-2000 Φ508-Φ760 ≤Φ2200 ≤35 1000-12000 ≤±2.0 ≤±3.0 ≤2.0 ≤12 ~275 50*10.5
8 20*2200 5.0-20 900-2000 Φ508-Φ760 ≤Φ2200 ≤35 1000-12000 ≤±2.0 ≤±3.0 ≤3.0 10-16 ~220 29*9.6
9 22*2200 5.0-20 900-2000 Φ508-Φ760 ≤Φ2200 ≤35 1000-12000 ≤±2.0 ≤±3.0 ≤3.0 10-16 ~220 29*9.6
10 25*2200 5.0-25 900-2000 Φ508-Φ760 ≤Φ2200 ≤35 1000-12000 ≤±2.0 ≤±3.0 ≤3.0 10-16 ~220 30*11
